- DLAB MS-H-ProT Magnetic Hot Plate Stirrer
$856.00
Available: In Stock
For laboratories in need of high quality equipment, the MS-H-ProT, offers a safe and price efficient solution, for tasks such as chemical synthesis, physical and chemical analysis that require a professional magnetic hot plate stirrer.
Enquiry about DLAB MS-H-ProT Magnetic Hot Plate Stirrer
Features:
- Operating temperature of up to 340°C
- Stir speed that can be adjusted in the range of 0 to 1500rpm
- Stir capacity for H2O – up to 20 liters
- Read the speed and temperature accurately from the hi-res LDC display
- Connect and use the external temperature sensor (PT1000) to get accurate readings at ±0.2°C
- The DLAB MS-H-ProT includes a special wide range timer function that can be set from 1 minutes to 99 hours and 59 minutes
- Excellent and near instant transfer of heat from the work plate, which is made of high quality stainless steel and covered with chemical resistant ceramic coating
- A safe magnetic hot plate stirrer that includes safety features suck as: explosion proofing, “HOT” indicator that blinks if the temperature is above 50°C, overheating protection with safety circuits
- Convenient functions like PC control and data transmission
- An assortment of accessories made by DLAB
Product Specs
| Specifications | MS-H-PROT |
| Work plate dimension | φ135mm(5 inch) |
| Work plate material | stainless steel cover with ceramic |
| Motor type | Brushless DC motor |
| Motor rating input | 18W |
| Motor rating output | 10W |
| Power | 550W |
| Heating output | 500W |
| Voltage | 100-120/200-240V 50/60Hz |
| Stirring positions | 1 |
| Max. stirring quantity[H2O] | 20L |
| Max. magnetic bar[length] | 80mm |
| Speed range | 100-1500rpm resolution±1rpm |
| Speed display | LCD |
| Temperature display | LCD |
| Heating temperature range | Room temp.-340°C, increment 1°C |
| Temperature control accuracy | ±1°C(<100°C) ±1%(>100°C) |
| Over temperature protection | 360°C |
| Temperature display accuracy | ±0.1°C |
| External temperature sensor | PT1000 (accuracy ±0.2) |
| “Hot” warning | 50°C |
| Timer function | 1min to 99h 59min |
| Data connector | RS232 |
| Protection class | IP42 |
| Dimension[WxDxH] | 160×280×85mm |
| Weight | 2.8kg |
| Permissible ambient temperature and humidity | 5-40°C, 80%RH |
Accessories
| Cat. No. | P/N | Descriptions | Power supply |
| 8030201110 | MS-H-ProT | LCD Digital Hotplate Magnetic Stirrer with Timer，stainless steel with ceramic coated hotplate，heating temperature up to 340°C,with PT1000 for free (18900016),need to buy support clamp 18900017 | USA plug,100V-120V/50Hz/60Hz |
| Cn plug,200V-240V/50Hz/60Hz | |||
| Euro plug,200V-240V/50Hz/60Hz | |||
| UK plug,200V-240V/50Hz/60Hz | |||
| MS-H-ProT 8030201110 +PA1000-A 18900016 +PT1000support clamp18900017 | MS-H-ProT package | ||
| MS-H-Pro+ 8030106110 +PA1000-A 18900016 +PT1000support clamp18900017 | MS-H-Pro+ aluminum hotplate package |
